Industrial Non-Clogging Static Sludge Mixers

We manufacture custom-engineered jet mixing systems designed specifically for your application requirements. Each system is individually priced based on tank geometry, material specifications, and performance requirements. Our engineers will provide a detailed proposal within 48 hours of receiving your tank configuration and mixing specifications.

We offer 316 stainless steel, 440 stainless steel for abrasion resistance, duplex and super duplex stainless steel, high chrome stainless steel, and FRP construction options.

Our jet mixing systems deliver significant energy savings compared to conventional diffused aerators and traditional mechanical agitators through efficient hydraulic operation. Contact our engineers for a site-specific energy analysis.

With no moving parts within the tank, our systems are virtually maintenance-free. All mechanical assemblies are located outside the tank for easy service access when needed.

Yes, our jet mixing systems operate effectively with fluctuating liquid levels from empty to full, making them ideal for equalization tanks and storm water applications.

Our non-clogging static sludge mixers can handle particles up to 2.2 inches in size. The systems feature large nozzle openings with 1-inch wall thickness and hardened nozzles with Brinell hardness of 450+ to resist abrasion from solids, along with optional pneumatic backflush systems to prevent particle buildup.

Our static sludge mixers are designed for 20+ year expected service life. With no rotating components inside the tank and all mechanical assemblies located outside for protection, these systems deliver decades of continuous operation with virtually zero maintenance requirements in demanding sludge applications.
